Part of the information displayed here for this preapproved system is available as a Microsoft Winword .doc file and part is available as a Microsoft Excel .xls file. Please click on both links and down load both file to be used with their respective programs to provide a complete printable Pre-approved system type.
| Project Number: | Project Name: | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Graphic Logic Location | Point Name Mnemonic | Point Type | Hardware Point | Virtual Point | Notes See Page # | Note # | |||||
| Point Description | System | Point | D0 | D1 | A0 | A1 | Comments | ||||
| 97 | Outside Air Temp Program | . | OAT_PG | PG | . | . | . | . | 1 | OAT=MIN(OAS...) | . |
| 98 | Outside Air Temp Trendlog | . | OAT_TL | TL | . | . | . | . | 1 | "OAT,OAS1,OAS2" | . |
| 99 | Outside Air Temperature | . | OAT | V | . | . | . | . | 1 | . | . |
| 1 | Outside Air Temp Upper | . | OAS1 | OTS | . | . | . | 1 | . | . | . |
| 2 | Outside Air Temp Lower | . | OAS2 | OTS | . | . | . | 1 | . | . | . |
| 3 | Exhaust Fan 1 Control | . | EF1 | CR1 | 1 | . | . | . | . | . | . |
| 4 | Exhaust Fan 1 Run Hours | . | EF1_TZ | TZ | . | . | . | . | 1 | . | . |
| 5 | Exhaust Fan 1 Program | . | EF1_PG | PG | . | . | . | . | 1 | . | . |
| 6 | Exhaust Fan 2 Control | . | EF2 | CR1 | 1 | . | . | . | . | . | . |
| 7 | Exhaust Fan 2 Run Hours | . | EF2_TZ | TZ | . | . | . | . | 1 | . | . |
| 8 | Exhaust Fan 2 Program | . | EF2_PG | PG | . | . | . | . | 1 | . | . |
| 9 | Sump Pump Alarm | . | SUMP | CRS1 | . | 1 | . | . | . | Set up alarm point | . |
| . | . | . | . | . | 2 | 1 | 0 | 2 | 7 | . | . |
